GNS-TX2 Push Pull Force Gauge, Force Measuring Gadget

Digital Push Pull Force Tester GNS-TX-II Series Force Gauge, Digital Push Pull Force Tester Meter GNS-TX-II, Portable Force Measuring Gadget GNS-TX2, Digital Push Pull Gauge GNS-TX2.

The GNS-TX2 (GNS-TX-II) is a digital push-pull force tester. It is used for industrial applications and features a digital LCD display to measure push and pull forces with high precision and resolution.

• Measurement modes: Offers three measurement modes for different testing needs: Real-time, Peak, and First peak.
• Unit conversion: Allows for conversion between four units: Newtons (N), Kilograms (Kg), Pounds (Lb), and Ounces (Oz).
• Gravity acceleration setting: The user can input the local gravity acceleration value for more accurate testing results.
• Limit settings: Provides the ability to set upper and lower limits for statistical analysis, with a buzzer alarm for readings that exceed these limits.
• Minimum force value shielding: This function allows users to ignore data that falls within a set minimum range.
• Automatic shutdown: The automatic shutdown time can be configured to conserve power when the device is not in use for a long period.

The GNS-TX2 push-pull force tester, also known as the GNS-TX-II model, is available in multiple capacity options. The capacity varies depending on the specific model variation.

• TX-II-2: 2N
• TX-II-5: 5N
• TX-II-10: 10N
• TX-II-20: 20N
• TX-II-50: 50N
• TX-II-100: 100N
• TX-II-200: 200N
• TX-II-500: 500N
• TX-II-1K: 1KN (1,000N)
