GR-QS-6 Control Valve

• GR-QS-6  Control Valve

Valve function One-way ow control function Pneumatic connection, port 1 QS-6 Pneumatic connection, port 2 QS-6 Adjustment component Knurled screw Type of mounting Either: Front panel mounting With through-hole With accessories Standard nominal ow rate in ow control direction 245 l/min Standard nominal ow rate in blocked direction 430 l/min Operating pressure 0.2 bar...10 bar Ambient temperature -10 °C...60 °C Material housing PA-reinforced Explosion protection The information in the certicate must be observed! Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) Mounting position optional Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) LABS (PWIS) conformity VDMA24364-B1/B2-L Media temperature -10 °C...60 °C Product weight 22 g Note on materials RoHS-compliant Material seals NBR Material release ring POM
