K48-M3852-00X Grease Gun

Grease Gun Set K48-M3852-00X Yamaha

Yamaha Grease Gun set K48-M3852-00X, Grease Gun MG70 K48-M3852-00X Yamaha.

The GREASE GUN K48-M3852-00X is a manual grease gun used for industrial lubrication, primarily on Yamaha surface-mount technology (SMT) placement machines and other precision equipment. It is specifically designed for high-precision greasing applications where manual control is necessary.

• Manufacturer: Yamaha.
• Design: The gun is a manual, hand-operated type that uses grease cartridges.
• Application: It is intended for maintenance on SMT chip mounter and placement machines to lubricate guide rails, wire rods, and bearings.
• Functionality: The grease gun works by creating strong pressure to deliver a controlled amount of lubricant to specific mechanical parts.

1. Prepare the gun for loading: Pull the plunger rod at the rear of the gun all the way out until it locks into place.
2. Load the grease cartridge:
   • Unscrew the head of the grease gun from the main barrel.
   • Insert a grease cartridge into the barrel. Insert the end with the foil seal first.
   • Remove the foil or pull-tab from the opposite end of the cartridge.
   • Reassemble the gun by screwing the barrel back onto the head.
3. Prime the gun:
   • Before fully tightening the head, loosen it by about half a turn to allow trapped air to escape.
   • Release the plunger rod from its locked position and press it inward.
   • Press the air bleeder valve, usually a small button or nipple near the nozzle, while pumping the handle. Stop when grease begins to emerge from the nozzle.
   • Retighten the head of the gun.
4. Apply grease:
   • Clean the grease fitting (zerk) on the machine before attaching the grease gun.
   • Press the grease gun's coupler firmly onto the fitting.
   • Pump the handle repeatedly to dispense grease into the component.
