GRL18-P1132 photoelectric retro-reflective sensor

GRL18-P1132  photoelectric retro-reflective sensor
Key Specifications

• Sensing Range: Maximum range of 0.03 m to 7.2 m (0.06 m to 6 m operational range).
• Output Type: PNP digital output with complementary switching functions (Light-ON / Dark-ON).
• Housing Design: M18 × 1 cylindrical threaded barrel made of robust metal.
• Light Source: High-visibility PinPoint LED emitting visible red light.
• Supply Voltage: 10 V DC to 30 V DC with low current consumption (~30 mA).
• Connection Type: Standard 2-meter, 4-wire PVC cable.
• Enclosure Rating: IP67 dust and water resistance for harsh factory environments.
• Adjustments: Includes an integrated potentiometer for manual calibration.

Pin Configuration & WiringThe sensor features a standard 4-wire configuration:

• Brown: Supply Voltage (+Vcc, 10–30 V DC)
• Blue: Ground (0V / GND)
• Black: Switching Output (PNP, Light-ON active)
• White: Switching Output (PNP, Dark-ON active)
