Sick GRL18-P2432 1066557 Photoelectric Sensor

SICK Photoelectric Sensor GRL18-P2432 1066557 Photoelectric retro-reflective sensor 175mm Light Spot PNP 0.06 m to 6 m Sensing Range 10V to 30V DC (Metal) Nickel-plated brass and ABS Housing

Specification/Additional Details

• Sensing Mode : Retro-Reflective
• Brand : SICK
• Model : GRL18-P2432
• Body Style : Cylindrical
• Part Number : 1066557
• Sensing range max. : 0.03 m to 7.2 m
• Sensing range : 0.06 m to 6 m

• Wave length : 650 nm

• Light source : PinPoint LED

• Light spot size (distance) : dia.175 mm (7 m)

• Supply voltage : 10 to 30V DC

• Indication : LED green, LED yellow

• Adjustment : Potentiometer

• Switching Output : PNP

• Connection : Male connector M12, 4-pin

• Ambient operating temperature : -25°C to +55°C

• IP rating : IP67

• Housing material : Metal, Nickel-plated brass and ABS
