GRTE18-N2432 proximity sensor

Key Specifications

• Sensing Principle: Diffuse, energetic proximity detection.
• Sensing Range: Max range up to 350 mm (with an operational range of 3 mm to 250 mm).
• Output Type: NPN with complementary light/dark switching.
• Connection Type: Standard M12, 4-pin male connector.
• Supply Voltage: 10 V DC to 30 V DC.
• Housing Geometry: Cylindrical M18 x 1 thread with axial optical alignment.
• Adjustment: Manual 270° potentiometer for fine-tuning sensitivity.
• Light Source: Infrared LED emitting at a wavelength of 850 nm.
