GTB10-P4211 sick sensor

Technical SpecificationsAccording to the official SICK datasheet and technical providers like

• Sensing Range: 20 mm to 950 mm (max).
• Light Source: PinPoint LED emitting visible red light (625 nm).
• Light Spot Size: Approximately Ø 8 mm at a distance of 700 mm.
• Switching Output: PNP output with light/dark switching modes, selectable via a toggle.
• Response Time: ≤ 500 µs with a switching frequency of 1,000 Hz.
• Adjustment: Features a 5-turn potentiometer for precise sensitivity tuning.
• Connection: Male M12, 4-pin connector.
• Supply Voltage: 10 V DC to 30 V DC.

Design and Durability

• Housing: Compact rectangular design (20 mm x 50 mm x 39 mm) made of plastic (ABS/PMMA).
• Enclosure Rating: IP67, making it dust-tight and resistant to water immersion.
• Operating Temperature: Works between –30 °C and +60 °C.
• Mounting: Uses the Q-Lock assembly system for rapid installation and alignment.
