GTS-800-PG-VB 8- motion control card
Key Specifications

• Controlled Axes: 8 axes (open or closed loop control)
• Architecture: DSP + FPGA for real-time motion planning
• Command Output: Pulse-only output mode (PG designation) with up to 1 MHz maximum output frequency
• Control Cycle: 250 µs sampling/control cycle
• Encoder Input: ABZ encoder input up to 8 MHz (quadrupled)
• Motion Modes: Point-to-point, continuous path, multi-axis synchronization, and linear/arc/helix/3D linear interpolation [1]
• Digital I/O: 16 isolated digital inputs and 16 digital outputs
• Bus Interface: 32-bit PCI bus slot

Software & Compatibility

• Programming Environments: Supports development via library files for Visual C++ (VC), Visual Basic (VB), C#, and LabVIEW.
• Operating Systems: Compatible with Windows (XP, 7) and Linux.
• Supported Drives: Works with major industrial servo/stepping drives including Panasonic, Yaskawa, Mitsubishi, and Sanyo Denki.
