H3-M6 Fotek multi-range power on-delay timer

H3-M6 Fotek multi-range power on-delay timer
Technical Specifications

• Time Ranges: 6 seconds, 60 seconds, 6 minutes, or 60 minutes
• Operating Voltage: Available in 12V/24V AC/DC or 110V/220V/380V AC variants
• Contact Rating: 10A at 250VAC (Relay output)
• Dimensions: Compact 40.0 x 50.0 mm body style
• Ambient Temperature: -20°C to +60°C [1]

Key Features

• Multi-range setting: Selectable time scales on a single unit.
• High repeatability: Low error margin (0.2% max of full scale).
• Durable relay life: Mechanical/electrical life rated up to 20 million operations. []
