H3CR-H8L 12S ACDC24V Omron Mount Timer Relay

H3CR-H8L 12S ACDC24V Omron Mount Timer Relay
Key Specifications

• Model Variants:
  • H3CR-H8L AC/DC24 S: Short time range (0.05 to 12 seconds).
  • H3CR-H8L AC/DC24 M: Long time range (0.05 to 12 minutes).
• Supply Voltage: 24V AC/DC.
• Output: DPDT (Double Pole Double Throw) contact configuration with a 5A resistive load rating at 250V AC.
• Mounting & Connection: 8-pin round socket/octal base. It supports DIN rail, surface, or flush mounting.
• Protection: IP40 rated for the panel surface.
• Operating Temperature: -10°C to 55°C.

Usage Notes

• Minimum Power-On Time: This timer requires the power to be on for at least 2 seconds to charge its internal capacitor for the OFF-delay operation.
• Repetition Period: Do not use the timer with a repetition period of less than 3 seconds, as this can lead to abnormal heat generation
