H3YN-4 OMRON TIMER 24V DC
Key Specification

• Supply Voltage: 24 VDC (allowable range: 20.6 to 26.4 VDC)
• Contact Output / Configuration: 4PDT (4-pole double-throw), rated at 3 A / 250 VAC (resistive load)
• Time Ranges: 0.1 seconds to 10 minutes (analog dial and dip switches)
• Operating Modes:
  • ON-delay
  • Interval
  • Flicker ON-start
  • Flicker OFF-start
• Pin Configuration: 14-pin plug-in terminal, compatible with standard MY-series power relay sockets (such as the PYF-series)
• Standards & Certifications: UL, CSA, CE, Lloyd’s
