H5CX-AD-N Omron counter meter 12 to 24v DC
Key Specifications
| Attribute | Detail |
|---|---|
| Product Type | Digital Timer (multifunction, twin timer) |
| Manufacturer | Omron Automation and Safety |
| Model Number | H5CX-AD-N |
| Supply Voltage | 24 VAC, 12 to 24 VDC |
| Time Range | 0.001 seconds to 9999 hours (selectable across 10 ranges) |
| Output Type | SPDT (1 form C) relay contact output |
| Contact Rating | 5A at 250 VAC / 30 VDC (resistive load) |
| Mounting Type | Panel mount (flush mounting) |
| Display Type | 4-digit LED display (characters can be switched between red, green, and orange) |
| Connection | Screw terminals |
| Operating Modes | 15 operating modes, including ON delay, repeat cycle, cumulative, and flicker operations |
| Protection Rating | IEC IP66 (panel surface, when fitted with waterproof packing) |
| Weight | Approx. 115 g |
Key Features
- Multifunctionality: Offers 15 distinct operating modes, making it a versatile tool for various automation tasks.
- High Visibility: Features a 4-digit display with 12 mm high characters whose color can be switched between red, green, and orange for improved readability.
- Compact Design: Has a short body depth, which helps in making thinner control panels.
- Enhanced Safety: The power supply and input circuits are isolated for safety and reliability. It also incorporates finger-safe terminals.
- Output Counter Function: Includes an output counter to monitor the number of times the output turns ON, which is useful for managing the service life of the timer or the connected load.
- Selectable Input Method: Allows selection between No-voltage (NPN) and Voltage (PNP) input methods with a DIP switch
