H7EC-BLM OMRON counter

H7EC-BLM OMRON counter
Key Specifications

• Power Supply: Self-powered via an internal 3.0V Lithium battery (CR2 model, approx. 3-year battery life).
• Counting Range: 0 to 999999.
• Counting Speed / Input Signal: Switchable/dual input constraints (e.g., up to 200 times/sec or minimum signal widths of 2.5ms / 30ms depending on mode).
• Reset Method: Panel/pushbutton reset.
• Dimensions / Cutout: Standard compact panel mount with an opening size of approximately 22.5 mm × 45 mm.
• Operating Temperature: -10°C to 40°C.
