Transformer For Hakko FX-888D Soldering Station QY01032442

220-240V AC To 26V AC Transformer For Hakko FX-888D Soldering Station

The Hakko FX-888D Transformer is a replacement transformer (220-240V) designed for use with the Hakko FX-888 and FX-888D soldering stations.

The HAKKO FX-888D (and the earlier FX-888) soldering station uses an internal transformer to convert the mains input voltage (e.g., 120V AC or 220-240V AC, depending on region) to a safe, low output voltage of 26V AC to power the soldering iron.

Transformer Specifications

The primary function of the internal transformer is safety and power delivery.

• Input Voltage: 220-240V AC.
• Output Voltage: The transformer provides an output of 26V AC to the soldering iron's heating element.
• Power Consumption: The station's total power consumption is rated at 70W, with the iron itself drawing 65W at 26V AC.
• Part Number: The replacement part number for the 220-240V transformer is QY01032442.
