HD11PC3 WENGLOR reflex photoelectric sensor
HD11PC3 WENGLOR reflex photoelectric sensor
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
HD11PC3 WENGLOR reflex photoelectric sensor
Technical Specifications
The primary technical details for this component include:
- Housing Material: Robust, M18 threaded stainless steel housing.
- Sensing Range: Adjustable from 35 mm to 120 mm.
- Light Source: Visible red light.
- Supply Voltage: 10 to 30 V DC.
- Output Type: PNP, Normally Open (NO).
- Switching Current: Maximum 200 mA.
- Switching Frequency: 600 Hz.
- Response Time: Quick 833 µs.
- Connection: Standard M12 × 1; 4-pin connector.
- Protection Rating: IP67 rated dust and water resistance, complete with short-circuit, overload, and reverse polarity protection
