HEDS-5640-A06 Rotary Encoder

HEDS-5640-A06 Rotary Encoder
Key Specifications

• Encoder Type: Incremental Optical (Transmissive)
• Resolution: 500 PPR (Counts per Revolution)
• Number of Channels: 3 Channels (2-channel quadrature with index pulse)
• Supply Voltage: 4.5V min to 5.5V max (5V DC nominal)
• Maximum Rotational Speed: 30,000 RPM
• Operating Temperature Range: -40°C to +100°C
• Shaft Diameter: 1/4 inch (6.35 mm)
• Termination Style: Solder / PC Pins
