HFD1612-ZH-3N subminiature signal relay
Key Specifications

• Coil Voltage: 12V DC.
• Contact Configuration: SPDT (1 Form C).
• Contact Rating:
  • Max Switching Current: 8A.
  • Max Switching Voltage: 250V AC / 220V DC.
• Coil Power: High sensitivity type, typically 200mW (approx.).
• Coil Resistance: 700 Ω.
• Mounting Type: Through-hole PCB mounting with PC Pin terminals.
• Contact Material: Silver Nickel (AgNi).
• Construction: Sealed (Wash tight) to allow for automatic soldering and cleaning.
