HFZ16 HFZ16 AIRTAC Cylinder

HFZ16 HFZ16 AIRTAC Cylinder

Key Features & Specifications:

• Model: HFZ16 (Double Acting)
• Bore Size: 16 mm
• Gripping Force (External, 0.5MPa): 34 N
• Total Stroke: 10 mm (5 mm per finger)
• Operating Pressure: 0.2 ~ 0.7 MPa
• Structure: Linear guide with ball bearing for high rigidity
• Mounting: Three-direction mounting with positioning pin hole for accuracy
• Weight: ~250g (approx. for standard unit)

Common Applications:

• Robot end-effectors
• Pick-and-place automation
• Mask manufacturing machines
