HG-KN73BJ-S100 MITSUBISHI

HG-KN73BJ-S100 MITSUBISHI AC brushless rotary servo motor
Key Specifications

• Rated Power: 750W / 0.75 kW
• Rated Speed: 3000 rpm (Max speed 6000 rpm)
• Rated Torque: 2.4 Nm
• Rated Current: 4.8 A
• Voltage: 200 Vac class
• Feedback: 17-bit absolute encoder (131072 ppr)
• Design Features: Built-in electromagnetic brake, oil seal, and straight shaft (IP65 rated)
