HGP-2A-F2R Hydromax pump
Model Code BreakdownThe model number specifies the pump's configuration according to standard Hydromax nomenclature:
- HGP-2A: Model series name.
- F: Mounting type, indicating a Flange Type mount.
- 2: Delivery capacity or displacement, specifically 2 cc/rev.
- R: Rotation direction, signifying Clockwise (as viewed from the shaft).
Key Technical Specifications
| Specification | Value |
|---|---|
| Displacement | 2.0 – 2.1 cc/rev |
| Rated Pressure | 210 kgf/cm² (21 MPa / ~3000 psi) |
| Max Pressure | 250 kgf/cm² (25 MPa / ~3500 psi) |
| Rated Speed | 1800 RPM |
| Max Speed | 5000 RPM |
| Min Speed | 1000 RPM |
| Weight | Approximately 1.69 kg (3.7 lbs) |
