Hitachi SP14Q006 LCD Module

Hitachi LCD Display Module LCD Screen SP14Q006 5.7 inch LCD Screen Module 320*240 LCD Display Panel For Hitachi CNC Machine

Specification/Additional Details

• Display Size : 5.7''
• Power Supply : 3.3/5.0V (Typ.)(VDD)
• Resolution : 320×240, QVGA 70PPI
• Operating Temperature : -20 ~ 70°C
• Backlight : WLED , 40K hours , W/O Driver
• Brand : Hitachi
• Model : SP14Q006
• Active Area : 115.185(W)x86.385(H) mm
• Outline Dimension : 167(H)x109(V) x10(D) mm
• Contrast Ratio : 5:1 (Typ.) (TM)
• Luminance : 60 cd/m² (Typ.)
• Panel Type : FSTN-LCD, LCM
• Response Time : 336/148 (Typ.)(Tr/Td)
• Support Color : Monochrome
• Signal Interface Type : Parallel Data (1ch, 4-bit) , 14 pins FPC
