HIOS HP-100 Digital Torque Meter

Digital Torque Meter HP-100 HIOS, HP-100 Torque Tester

The HIOS HP-100 Digital Torque Meter is a precision instrument designed for industrial use, typically used for measuring and testing the torque of electric screwdrivers, pneumatic screwdrivers, and torque wrenches. It can measure torque in both clockwise and counterclockwise directions.

Key Specifications

Measuring Range 0.15 - 10 Nm
Accuracy Within ±0.5% (F.S.)
Display Digital LCD HD display, some versions with 3.5-inch graphic display
Measurement Modes PEAK, TR1 (torque waveform), TR2 (continuous torque waveform) or TRACK
Data Output Data can be imported to a computer via USB or Bluetooth (standard on some new versions).
Memory Stores up to 100 data items.
Power Rechargeable Ni-MH battery (1.2 V / 5 cells), with approximately 2.5 hours of continuous operation on a full charge.
Dimensions 230 x 124 x 65.2 mm (W x D x H)
Weight Approximately 1.8 - 1.94 kg



Features and Applications

  • Automatic Functions: Features automatic zero adjustment and automatic shutdown after 10 minutes of inactivity.
  • Measurement Analysis: Can measure and display maximum, minimum, and average torque values.
  • Versatile Use: Used in quality control to check the torque of various rotating units, sort screws by required torque, and perform destructive testing of smaller parts.
  • Accessories: With a joint simulator, AC adapter, carry case, and fidaptors for different drive sizes (e.g., H5, 1/4HEX).
