HT-6510N Digital Tension Meter

HT-6510N Screen Tension Meter Steel Mesh Tension Measurement Screen Tension Tester, HT-6510N Digital Screen Tension Tester for Screen Printing, Screen Printing Tension Tester Gauge HT-6510N

The HT-6510N is a portable, battery-powered digital screen tension meter used for measuring the tension of mesh screens in screen printing and other industrial applications. It provides accurate, digital readings to help avoid measurement errors that can occur with manual methods.

Key features

• Digital LCD display: Shows a clear, precise reading of the screen's tension.
• Measurement range: 7 to 40 N/cm (Newtons per centimeter).
• Display range: 0 to 50 N/cm (Newtons per centimeter).

• High resolution: The display has a resolution of 0.1 N/cm.
• Unit conversion: Allows for switching between N/cm and kg/cm.
• Data output capability: Can connect to a PC via USB or RS-232 data output for logging measurements. (Optional)
• Portability: The compact, lightweight design (around 490g without batteries) makes it easy to use and transport.
• Power source: Uses four 1.5V AAA (UM-4) batteries.
• Standard accessories: Comes with a calibration block, carrying case, and an operation manual.

Applications

• Screen printing: Ensures consistent print quality by confirming the screen mesh is stretched to the correct tension.
• Electronics manufacturing: Measures tension in SMT (Surface Mount Technology) stencils to ensure accurate solder paste deposition.
• Quality control: Provides a reliable method for production facilities to track and verify screen and stencil quality.
