HWP-C804-01-23-HL-P Intelligent Digital Display Measurement and Control Instrument

HWP-C804-01-23-HL-P Intelligent Digital Display Measurement and Control Instrument

Key Specifications & Technical Breakdown

• Core Function: Serves as a digital process indicator with built-in control relays.
• Input Voltage: Operates on a standard AC 220V power supply line.
• Display Configuration (C804): Features a localized digital LED readout screen to display real-time process values. (Note: Its sibling line, the T804, features an added LED light column/bar-graph visual alongside the numeric display).
• Alarm Outputs (HL): Indicates a dual-relay configuration designed for process boundary control—specifically High (H) and Low (L) alarm thresholds to trigger external machinery like pumps, valves, or safety buzzers.
• Auxiliary Power (-P): Outfitted with an integrated feed distribution loop (typically a DC 24V auxiliary power output) to directly energize 2-wire or 3-wire external sensors without needing a separate transformer.
