IFM IB0016 IBE2020-FBOA Inductive Sensor

IFM Inductive Sensor IB0016-IBE2020-FBOA Cylindrical, Normally open / Normally closed; (selectable) Output, 20mm Sensing Range, 20V to 250V AC/DC Operating Voltage, 25 Hz Switching frequency, Size=Ø 34 mm Total length 98 mm

Specification/Additional Details

• Sensing Distance : 20 mm
• Usage : for Industrial
• Brand : IFM
• Model : IB0016 IBE2020-FBOA
• Operating Voltage : 20V to 250V AC/DC
• Type : Cylindrical

• Function display : Yes

• Output function : NO/NC programmable

• Switching frequency : 25 Hz

• Connection principle : 2-wire

• Size : Dia.34mm L- 98 mm

• Connection : terminals; Cable sheath; Cable gland: M20 X 1.5

• Protection rating : IP65

• Housing material : PBT
