IFM208 IFM SENSOR
| Attribute | Detail |
|---|---|
| Sensor Type | Inductive sensor |
| Sensing Range | 7 mm (non-flush mountable) |
| Housing | M12 x 1 threaded type, L = 79 mm, stainless steel |
| Output Function | Normally open (NO), PNP/NPN electrical design |
| Operating Voltage | 10...36 V DC |
| Protection | IP 67 and IP 69K (high ingress protection) |
| Operating Temperature | -40...85 °C |
| Connection | 6 m PUR cable |
Key Features
- High Environmental Resistance: The sensor offers high ingress protection ratings of IP 67 and IP 69K, making it suitable for wet and harsh conditions, including high-pressure washdowns.
- Durable Construction: The housing is made of stainless steel (body) and brass (lock nuts), contributing to its high shock and vibration resistance.
- Automotive Approval: It has E1 type approval by the German Federal Motor Transport Authority (Kraftfahrt-Bundesamt), indicating high noise immunity and suitability for automotive applications.
- Visible Status Indication: The unit includes 4 x 90° yellow LEDs for clear visibility of the switching status from multiple angles.
