IFRM04N15A1L INDUCTIVE SENSOR

IFRM04N15A1L INDUCTIVE SENSOR
Key Specifications

• Sensor Type: Inductive Proximity Sensor
• Body Style: Smooth Barrel, Miniature
• Dimensions: 4 mm diameter, 25 mm length
• Sensing Distance (): 1 mm (Flush/Shielded)
• Output Circuit: NPN Make Function (Normally Open/NO)
• Supply Voltage: 10 – 30 V DC
• Switching Frequency: < 5 kHz
• Connection: Pre-cabled, 2 meter
• Housing Material: Stainless Steel
• Protection Rating: IP 67
• Temperature Range: -25 to +75 °C Baumer +4

Technical Highlights

• Miniature Design: The 4 mm diameter makes it ideal for space-constrained environments.
• Flush Mounting: The sensor is flush-mountable (shielded), allowing it to be embedded directly into metal components.
• High Switching Speed: Suitable for fast-moving detection applications (< 5 kHz).
• Robustness: IP67 rating ensures high protection against dust and water immersion.
• NPN Output: Specifically uses NPN Normally Open switching logic.

Common Applications

• Automated manufacturing lines
• Positioning and counting of metal parts
• Robotics and handling equipment
• High-speed automation tasks

Equivalent/Similar Products

• PNP Version: If a PNP output is needed instead of NPN, the IFRM 04P15A1/L is the corresponding model.
• Connector Version: For a plug-in connection rather than a fixed cable, models like the IFRM 04N15A3/S35L may be used
