IGC250 IFM Sensor
Key Specifications

• Housing: Threaded M18 x 1 / L = 70 mm stainless steel (316L) full-metal housing
• Sensing Range: 4.5 mm (flush mountable)
• Electrical Design: PNP, normally closed (NC) output
• Operating Voltage: 10...30 V DC
• Switching Frequency: 100 Hz
• Protection Rating: IP68 (resistant to oils, coolants, and lubricants; pressure rating up to 100 bar on the sensing face)
• Special Features: Ferrous metal selective detection with aluminum chip immunity (correction factor K = 0) and gold-plated contacts.
