IGS209 IFM SENSOR

IGS209 IFM SENSOR
Core Specifications

• Sensing Range: 12 mm with a non-flush mounting type.
• Housing: M18 x 1 threaded barrel design made of robust white bronze-coated brass.
• Electrical Design: Supports both 3-wire DC PNP and 2-wire DC PNP/NPN configurations.
• Output Function: Normally open (NO).
• Operating Voltage: 10 to 30 V DC.
• Connection: M12 connector with gold-plated contacts for high reliability.

Key Features

• Visual Indicators: Features a yellow LED for switching status (visible from 4 x 90°) and a red LED as an optical setting aid for easier installation.
• Durability: Rated IP67 for protection against dust and water immersion, making it suitable for harsh industrial conditions.
• Protection: Includes built-in protection against short circuits, overloads, and reverse polarity.
• Performance: Offers a high switching frequency of up to 300 Hz.
