IGS212 IFM Sensor
Key Specifications

• Type: Inductive proximity sensor
• Part / Model Number: IGS212 / IGK3008BBPKG/US-104
• Sensing Range: 8 mm (flush mountable / shielded)
• Housing: M18 x 1 threaded cylindrical barrel (length = 70 mm), white bronze-coated brass
• Output Function: PNP, normally open (NO)
• Operating Voltage: 10...30 VDC
• Switching Frequency: 400 Hz
• Max Load / Current Rating: 100 mA
• Connection Type: M12 connector with gold-plated contacts (3-pin, A-coded)
• Environmental Protection: IP67 rating
• Operating Temperature: -25 to 70 °C
• Weight: 51.7 g
