IGS279 IFM Sensor
Product characteristics

Electrical design PNP
Output function normally open
Sensing range[mm] 8
Housing threaded type
Dimensions[mm] M18 x 1 / L = 45

Application

Special feature Gold-plated contacts; Increased sensing range; Correction factor K = 1; Magnetic-field immune
Application Suitable for industrial, mobile, cooling and lubricating applications; Industrial applications / factory automation
Magnetic-field immune yes
Max. magnetic field immunity[mT] 300

Electrical data

Operating voltage[V] 10...30 DC
Current consumption[mA] < 20
Protection class III
Reverse polarity protection yes

Outputs

Electrical design PNP
Output function normally open
Max. voltage drop switching output DC[V] 2.5
Permanent current rating of switching output DC[mA] 100
Switching frequency DC[Hz] 2000
Short-circuit protection yes
Overload protection yes

Detection zone

Sensing range[mm] 8
Real sensing range Sr[mm] 8 ± 10 %
Operating distance[mm] 0...6.48
Increased sensing range yes

Accuracy / deviations

Correction factor steel: 1 / stainless steel: 1 / brass: 1 / aluminium: 1 / copper: 1
Hysteresis[% of Sr] 3...15
Switch point drift[% of Sr] -10...10
Correction factor K = 1 yes

Operating conditions

Ambient temperature[°C] -40...85
Protection IP 65; IP 66; IP 67; IP 68; IP 69K

Tests / approvals

EMC
EN 61000-4-2 ESD 4 kV CD / 8 kV AD
EN 61000-4-3 HF radiated 10 V/m
EN 61000-4-4 Burst 2 kV
EN 61000-4-6 HF conducted 10 V
EN 55011 class B
Vibration resistance
EN 60068-2-6 Fc 20 g (10...3000 Hz) / 50 sweep cycles, 1 octave per minute, in 3 axes
Shock resistance
EN 60068-2-27 Ea 100 g 11 ms half-sine; 3 shocks each in every direction of the 3 coordinate axes
Continuous shock resistance
EN 60068-2-27 40 g 6 ms; 4000 shocks each in every direction of the 3 coordinate axes
Fast temperature change
EN 60068-2-14 Na TA = -40 °C; TB = 85 °C; t1 = 30 min; t2 = < 10 s; 50 cycles
Salt spray test
EN 60068-2-52 Kb severity level 5 (4 test cycles)
MTTF[years] 464


IGS279 IFM Sensor
Product characteristics

Electrical design PNP
Output function normally open
Sensing range[mm] 8
Housing threaded type
Dimensions[mm] M18 x 1 / L = 45

Application

Special feature Gold-plated contacts; Increased sensing range; Correction factor K = 1; Magnetic-field immune
Application Suitable for industrial, mobile, cooling and lubricating applications; Industrial applications / factory automation
Magnetic-field immune yes
Max. magnetic field immunity[mT] 300

Electrical data

Operating voltage[V] 10...30 DC
Current consumption[mA] < 20
Protection class III
Reverse polarity protection yes

Outputs

Electrical design PNP
Output function normally open
Max. voltage drop switching output DC[V] 2.5
Permanent current rating of switching output DC[mA] 100
Switching frequency DC[Hz] 2000
Short-circuit protection yes
Overload protection yes

Detection zone

Sensing range[mm] 8
Real sensing range Sr[mm] 8 ± 10 %
Operating distance[mm] 0...6.48
Increased sensing range yes

Accuracy / deviations

Correction factor steel: 1 / stainless steel: 1 / brass: 1 / aluminium: 1 / copper: 1
Hysteresis[% of Sr] 3...15
Switch point drift[% of Sr] -10...10
Correction factor K = 1 yes

Operating conditions

Ambient temperature[°C] -40...85
Protection IP 65; IP 66; IP 67; IP 68; IP 69K

Tests / approvals

EMC
EN 61000-4-2 ESD 4 kV CD / 8 kV AD
EN 61000-4-3 HF radiated 10 V/m
EN 61000-4-4 Burst 2 kV
EN 61000-4-6 HF conducted 10 V
EN 55011 class B
Vibration resistance
EN 60068-2-6 Fc 20 g (10...3000 Hz) / 50 sweep cycles, 1 octave per minute, in 3 axes
Shock resistance
EN 60068-2-27 Ea 100 g 11 ms half-sine; 3 shocks each in every direction of the 3 coordinate axes
Continuous shock resistance
EN 60068-2-27 40 g 6 ms; 4000 shocks each in every direction of the 3 coordinate axes
Fast temperature change
EN 60068-2-14 Na TA = -40 °C; TB = 85 °C; t1 = 30 min; t2 = < 10 s; 50 cycles
Salt spray test
EN 60068-2-52 Kb severity level 5 (4 test cycles)
MTTF[years] 464
