IGT204 Proximity sensor

IGT204 Proximity sensor
Core Technical SpecificationsThe specific parameters for this model listed on the include:

• Sensing Range: 8 mm (with an increased sensing range design)
• Installation/Mounting: Flush mountable
• Electrical Design: DC PNP
• Output Function: Normally Open (NO)
• Operating Voltage: 10 to 30 V DC
• Housing Type: M18 x 1 threaded cylindrical barrel
• Overall Length: 45 mm (or 46 mm depending on exact thread tolerances)
• Connection Type: 1 x M12 connector (3-pin with gold-plated contacts)
• Ingress Protection Rating: IP67
• Switching Frequency: 400 Hz

Key Material Correction FactorsBecause i is an inductive sensor, the detection distance varies depending on the type of metal targeted. The correction factors for the IGS204 include

• Mild Steel: 1.0 (Full 8 mm range)
• Stainless Steel: Approx. 0.7
• Brass: Approx. 0.5
• Aluminium: Approx. 0.4
• Copper: Approx. 0.3
