IGT207 Proximity sensor
Core Technical Specifications
| Parameter | Specification |
|---|---|
| Sensor Type | Inductive Proximity Sensor |
| Housing Design | Cylindrical M18 x 1 Threaded (Brass with white bronze coating) |
| Sensing Range | 8 mm (Increased sensing range) |
| Electrical Design | PNP |
| Output Function | Normally Closed (NC) |
| Operating Voltage | 10 to 30 V DC |
| Mounting Type | Flush Mountable |
| Connection Type | M12 Connector (3-pin, gold-plated contacts) |
| Protection Rating | IP 68 |
| Switching Frequency | 400 Hz |
| Ambient Temperature | -25 °C to 70 °C |
Key Features & Benefits
- Harsh Industrial Resilience: With an IP 68 protection rating, this sensor is fully protected against dust ingress and long-term immersion in water, making it robust against aggressive industrial cutting fluids and coolants.
- Enhanced Sensing Distance: Features an extended 8 mm sensing range, minimizing the risk of mechanical damage caused by target components moving too close to the sensor face.
- High Signal Reliability: Equipped with gold-plated contacts that ensure stable signal transmission and resistance to corrosion over a long lifespan.
- 360° Visual Feedback: Includes a highly visible yellow LED status indicator structured with 4 windows spaced at 90° intervals, making troubleshooting visible from any angle.
