II5687 IFM SENSOR
Product characteristics
| Electrical design | PNP/NPN |
| Output function | normally open / normally closed; (selectable) |
| Sensing range[mm] | 10 |
| Housing | threaded type |
| Dimensions[mm] | M30 x 1.5 / L = 81 |
Electrical data
| Operating voltage[V] | 10...55 DC |
| Protection class | II |
| Reverse polarity protection | yes |
Outputs
| Electrical design | PNP/NPN |
| Output function | normally open / normally closed; (selectable) |
| Max. voltage drop switching output DC[V] | 4.6 |
| Minimum load current[mA] | 4 |
| Max. leakage current[mA] | 0.5 |
| Permanent current rating of switching output DC[mA] | 400 |
| Switching frequency DC[Hz] | 450 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
Detection zone
| Sensing range[mm] | 10 |
| Real sensing range Sr[mm] | 10 ± 10 % |
| Operating distance[mm] | 0...8.1 |
Accuracy / deviations
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminium: 0.3 / copper: 0.2 |
| Hysteresis[% of Sr] | 1...15 |
| Switch point drift[% of Sr] | -10...10 |
Operating conditions
| Ambient temperature[°C] | -25...80 |
| Protection | IP 67 |
Tests / approvals
| EMC |
|
||||
| MTTF[years] | 1699 |
Mechanical data
| Weight[g] | 501.3 |
| Housing | threaded type |
| Mounting | flush mountable |
| Dimensions[mm] | M30 x 1.5 / L = 81 |
| Thread designation | M30 x 1.5 |
| Materials | brass nickel-plated; sensing face: PBT |
Displays / operating elements
| Display |
|
Accessories
| Items supplied |
|
Remarks
| Pack quantity | 1 pcs. |
Electrical connection
| Cable | 10 m, PUR / PVC; 2 x 0.5 mm² |
