IIT228 Proximity sensor

IIT228 Proximity sensor
Key Technical Specifications

• Housing Design: Cylindrical, M30 x 1.5 threaded barrel made from premium V4A / 316L stainless steel.
• Sensing Face: Fully shielded / flush mountable.
• Sensing Distance: up to 10 mm detection range.
• Electrical Output: 3-wire DC PNP with a normally open (NO) contact form.
• Operating Voltage: 10V to 30V DC.
• Current Rating: Up to 100 mA maximum output current.
• Switching Frequency: 50 Hz.
• Electrical Connection: Integrated 4-pin M12 connector with gold-plated contacts.
• Visual Status: Features a 4 x 90° yellow LED switching status indicator.

Environmental & Durability Ratings

• Ingress Protection: Heavily sealed with IP68 and IP69K ratings.
• Temperature Limits: Highly resilient, supporting operating temperatures from 0°C to 100°C (32°F to 212°F).
• Chemical Resistance: Specially built to withstand aggressive cleaning chemical agents and high-pressure washdown routines.
• Pressure Rating: Rated up to 100 bar (10 MPa)
