IFM IM5020 Inductive Proximity Sensor
IME3015BFPKG
Inductive Sensor IM5020 IME3015BFPKG IFM, 15 mm (flush mountable), PNP (normally open / normally closed selectable via wire bridge)
The ifm electronic IM5020 (IME3015BFPKG) is a flush-mountable, rectangular inductive proximity sensor designed for industrial automation, featuring a 15 mm sensing range and a PNP output.
Specifications
| Sensing Range | 15 mm (flush mountable) |
| Output Type | PNP (normally open / normally closed selectable via wire bridge) |
| Operating Voltage | 10–36 V DC |
| Switching Frequency | 250 Hz |
| Housing Material | PPE (plastic) |
| Dimensions | 40 x 40 x 120 mm |
| Protection Rating | IP65 |
| Operating Temperature | -25–80 °C |
| Short-Circuit Protection | Yes (pulsed) |
| Reverse Polarity Protection | Yes |
