IM5117 inductive proximity sensor

IM5117 inductive proximity sensor

• Sensing Range: 40 mm (Non-flush mountable)
• Electrical Design: DC PNP
• Output Function: Normally Open (NO)
• Operating Voltage: 10 to 36 V DC
• Current Rating: 200 mA
• Switching Frequency: 60 Hz
• Housing Dimensions: 40 x 40 x 54 mm (Rectangular Polyamide body)
• Connection Type: M12 connector (4-pin, A-coded, rotatable)
• Protection Rating: IP 67 (Suitable for harsh industrial environments)

• Flexible Alignment: The sensing face can be manually adjusted to 5 different positions, allowing versatile mounting orientations.
• High Visibility Displays: Equipped with corner LEDs that remain clearly visible from any angle. A green LED indicates operational power status, while a yellow LED displays the active switching status.
• Built-in Circuit Protection: Features short-circuit, overload, and reverse polarity protections to ensure system safety.
