IFM Inductive Sensor IN5213
IN-3004-BPKG/6M/PH

The IFM IN5213 is a particularly space-saving rectangular inductive sensor with a 4 mm sensing range, designed for use in applications where space is restricted. It operates with a PNP output and features a 6-meter PUR cable connection.

Product specifications

Electrical data

• Operating voltage: 10–36V DC
• Current consumption: 15 mA (at 24V)
• Protection class: II
• Reverse polarity protection: Yes

Outputs

• Electrical design: PNP
• Output function: Normally open
• Permanent current rating: 250 mA
• Switching frequency: 1,300 Hz
• Short-circuit protection: Yes (pulsed)
• Overload protection: Yes

Mechanical data

• Housing: Rectangular (40 x 12 x 26 mm)
• Mounting: Non-flush mountable
• Materials: Housing: PBT.
• Electrical connection: 6-meter PUR cable (3 x 0.5 mm²)
• Ambient temperature: -25–80 °C
• Ingress protection: IP67

Features

• Designed for limited-space applications.
• High switching frequency.
• Wide operating temperature range.
• LED status indicator.
