IR1020-01BG SMC regulator

IR1020-01BG SMC regulator

Key Technical SpecificationsBased on the manufacturer's data and expert listings:

• Pressure Range: Sets output pressure from 0.01 to 0.8 MPa (approx. 1.5 to 116 psi).
• Maximum Supply Pressure: Rated for a maximum inlet of 1.0 MPa (approx. 145 psi).
• Port Size: Features 1/8" Rc (conical thread) inlet and outlet ports.
• Included Accessories: The "BG" suffix indicates it comes equipped with both a Mounting Bracket and a Pressure Gauge.
• Precision Metrics:
  • Sensitivity: Within 0.2% of full span.
  • Repeatability: Within ±0.5% of full span.
• Operating Temperature: Suitable for environments between -5 to 60°C (with no freezing).

Core Features

• High Relief Flow: Compared to older models like the SMC IR201, this series offers nearly five times the relief flow, allowing for faster response when downstream pressure exceeds the set point.
• Versatile Mounting: The optional pressure gauge and bracket can be mounted on either the front or back of the unit for flexible installation.
• Nozzle-Flapper Pilot Mechanism: Uses a specialized pilot mechanism to detect fine pressure variations and maintain high stability even under varying flow conditions.
