IR2000-F02-A solenoid valve

IR2000-F02-A solenoid valve
Part Number Breakdown

• IR: Precision Regulator series.
• 2: Body size 2 (width of 50 mm).
• 0: Basic handle adjustment type.
• 0: Set pressure range of 0.005 to 0.2 MPa (0.73 to 29 psi).
• F: G-thread type connection.
• 02: 1/4 inch supply and control side connection diameter.
• A: New generation model variation featuring a high flow rate and an increased relief flow capacity.

Key Specifications

• Compatible Fluid: Compressed Air
• Max Supply Pressure: 1.0 MPa (10 bar)
• Setting Sensitivity: Within 0.2% of Full Span
• Repeatability: Within ±0.5% of Full Span
• Air Consumption: 1 l/min or less
• Exhaust Mechanism: Included (Air bleed relief type)
• Operating Temperature: -5°C to +60°C (with no freezing)
