IR2020-02B-A (SMC) SMC REGULATOR

IR2020-02B-A (SMC) SMC REGULATOR
Part Number Breakdown

• IR: Precision Regulator Series
• 2: Body size (IR2000 series)
• 0: Standard type (Basic type)
• 20: Set pressure range up to 0.8 MPa (116 Psi)
• -02: Port connection thread size Rc 1/4"
• B: Includes a mounting bracket
• -A: New modular design/generation indicator

Key Technical Specifications

• Fluid: Compressed air (dry, filtered to 0.3 µm)
• Maximum Supply Pressure: 1.0 MPa (10 bar / ~145 Psi)
• Setting Pressure Range: 0.01 to 0.8 MPa (1.45 to 116 Psi)
• Setting Accuracy/Sensitivity: Within 0.2% of Full Span
• Repeatability: Within ±0.5% of Full Span
• Operating Temperature Range: -5°C to +60°C
• Weight: ~300g
