IR2020-02BG-A SOLENOID VALVE

IR2020-02BG-A SOLENOID VALVE
Part Number BreakdownThe specific model alphanumeric code indicates the exact layout and features of the hardware:

• IR2020: Refers to the SMC IR2000 series medium-size precision regulator. The trailing "20" signifies a standard setting pressure range of 0.01 to 0.8 MPa (approx. 1.45 to 116 Psi).
• 02: Designates the 1/4" PT / Rc connection thread size.
• B: Includes a mounting bracket accessory.
• G: Includes a round pressure gauge accessory bundled with the shipment.
• A: Indicates it belongs to the updated "New IR" generation, which features a compact, lightweight body design and significantly higher relief flow rates compared to older versions.

Core Technical SpecificationsThe operational performance thresholds for this exact unit include:

• Fluid Medium: Clean, filtered compressed air.
• Maximum Supply Pressure: 1.0 MPa (10 Bar).
• Set Pressure Range: 0.01 to 0.8 MPa.
• Sensitivity: Within 0.2% of Full Span, allowing for extremely fine micro-adjustments.
• Repeatability: Within \(\pm0.5\%\) of Full Span.
• Ambient Fluid Temperature: –5 to 60°C (with no freezing)
