ITV3050-044N electro-pneumatic regulator

ITV3050-044N electro-pneumatic regulator

Model Breakdown & Part Number MeaningAccording to the official  each digit in the part number designates a specific hardware feature:

Technical Specifications

• Linearity: Within ±1% of Full Scale (F.S.)
• Hysteresis: Within 0.5% of Full Scale (F.S.)
• Sensitivity: Within 0.2% of Full Scale (F.S.)
• Enclosure Rating: IP65 equivalent (Dust-tight and water-jet resistant)
• Display Type: Built-in, bright digital LED display for pressure monitoring
• Operating Temperature: 0 to 50°C (with no freezing)
• Net Weight: 645 grams

Common ApplicationsThis regulator is used where automated, dynamic pressure tracking is mandatory:

• Controlling force on pneumatic cylinders and clamping arms.
• Governing precise air volume in spray-painting or coating applications.
• Managing tension control in film, paper, or wire winding machinery.
• Adjusting pilot pressure lines for larger main process valves.

If you are setting this unit up or replacing an old one, let me know:

• Do you require a matching cable connector (straight or right-angle type)?
• Do you need an L-bracket or flat bracket for mounting?

I can provide the exact SMC accessory part numbers to match your configuration.
