IW5058 inductive Proximity sensor
Technical SpecificationsThe electrical, mechanical, and operational parameters of the include:
| Parameter | Specification |
|---|---|
| Sensor Type | Inductive |
| Electrical Design | DC PNP |
| Output Function | Normally Open (NO) |
| Sensing Range | 8 mm |
| Operating Distance | 0 to 6.5 mm |
| Operating Voltage | 10 to 36 V DC |
| Current Rating | 250 mA |
| Switching Frequency | 300 Hz |
| Housing Material | Polybutylene Terephthalate (PBT plastic) |
| Dimensions | 60 mm × 36 mm × 10 mm |
| Mounting Type | Non-flush mountable (unshielded) |
| Protection Rating | IP 67 |
| Connection Type | Pre-cabled (2-meter PVC cable, 3-wire) |
