JS24MN-K Power Relay

Fujitsu JS24MN-K Electromagnetic Power Relay SPST-NO 24V DC Coil Voltage, 8A / 250VAC AC contacts rating, 8A / 24VDC DC contacts rating, max. 150V DC, max. 400V AC Switched voltage, PCB Mounting, Miniature.

Specification/Additional Details

• Voltage : 24V
• Usage/Application : I/O Modules, Timer, Heater control, Air Conditioner etc.
• Product Type : Electromagnetic Power Relay
• Contacts configuration : SPST-NO
• Rated coil voltage : 24V DC
• Contact current max. : 8A

• AC contacts rating : 8A / 250V AC @R (at resistive load)

• DC contacts rating : 8A / 24V DC  @R (at resistive load)

• Switched voltage : max. 150V DC, max. 400V AC

• Mounting : PCB

• Body dimensions : 29x10x12.5mm

• Operating temperature : -40 to 85°C
