K8AK-PH1 Omron SSR RELAY

K8AK-PH1 Omron SSR RELAY
Key Technical Specifications

• Functions Monitored: Simultaneous monitoring of phase sequence (reversal) and phase loss (both at start-up and during operation).
• Measuring Range: 200 to 480 V AC (3-phase, 3-wire systems).
• Output Configuration: One DPDT (Double Pole Double Throw) electromechanical relay output.
• Contact Rating: 5 A at 250 V AC (Resistive load).
• Response Time: Extremely fast operation with a 0.1-second maximum reaction time.
• Mounting: Designed for standard 22.5 mm wide DIN-rail mounting.
• Status Monitoring: Features built-in LED indicators (Green for power, Yellow for relay output status).
