KBPC2510 bridge rectifier

KBPC2510 bridge rectifier
KBPC2510 Bridge Rectifier SpecificationsIf your inquiry relates to the bridge rectifier, it is frequently used in power supplies, battery chargers, and motor drives. Its core specifications include:

• Maximum Average Forward Current (\(I_{F(AV)}\)): 25A
• Maximum Repetitive Peak Reverse Voltage (\(V_{RRM}\)): 1000V
• Surge Current Rating (\(I_{FSM}\)): 300A - 400A (non-repetitive)
• Terminals: Four 0.25" (6.35mm) quick-disconnect/Faston lugs
• Package Type: KBPC metal or epoxy casing for high heat dissipation

The rectifier contains four internal diodes arranged in a bridge configuration. The metal/epoxy case is electrically isolated and features printed markings on the top for:

• AC (~): Two terminals for the incoming alternating current
• + / -: DC output terminals For tips on how to check and test a bridge rectifier unit:
