KG5043 Proximity sensor

KG5043 Proximity sensor
Key Technical Specifications

• Housing: M18 x 1 threaded cylindrical body made of durable PBT plastic.
• Sensing Range: 8 mm nominal, which can be easily calibrated and adjusted using an on-board potentiometer.
• Electrical Design: DC PNP with a Normally Open (NO) switching output.
• Operating Voltage: 10 to 36 V DC.
• Mounting Type: Non-flush mountable.
• Connection: 2-meter prewired 3-wire PVC cable.
• Environmental Protection: IP67 rated (dust-tight and water-resistant for harsh environments).
• Visual Indicator: Features a highly visible yellow LED status light to indicate switching output status. [1, 2, 3, 4, 5, 6, 7, 8]

Common Industrial ApplicationsBecause it is a capacitive sensor, it can "see through" non-metallic container walls. Common use cases include:

• Monitoring liquid or bulk material levels inside plastic bins or glass tubes.
• Checking the presence of cardboard boxes or packaging layers.
• Detecting sheets of glass, wood panels, or plastic components on automation conveyor systems.
• Standard Wiring ConfigurationThis is a standard 3-wire DC sensor. The connection layout is typically as follows:
  • Brown Wire: Positive Power Supply (+VDC, 10–36V)
  • Blue Wire: Negative Power Supply (0V / Ground)
  • Black Wire: PNP Switching Output (Connects to your PLC or load, switching to +VDC when an object is detected)
