DC Solenoid Electromagnet KK-0530B 24VDC Push Pull Type

Push Pull Type Micro Electromagnet KK-0530B 24VDC, DC12V 24V Through Push Pull Small DC Electromagnet 0530B

The KK-0530B 24VDC is a model number for a push-pull type DC solenoid electromagnet. It is designed to provide linear motion for automation equipment.

Key Specifications

• Model: KK-0530B
• Rated Voltage: 24 VDC
• Rated Current: 300 mA
• Action Type: Push and Pull type (linear motion, plunger spring return)
• Force:
  • Initial Force (0mm travel): 5 Newton (approx. 500g or 0.7kg holding force)
  • Keeping Force (at 10mm travel): approx. 700g
• Stroke (Travel Distance): 10 mm
• Electric Time: The product is typically designed for intermittent use (short bursts of less than 1 minute).
• Coil Resistance: Approx. 25 ohms
• Body Size: Approx. 30 x 15 x 15 mm (LWH)

Typical Applications

These solenoids are widely used in various automation control systems, including:

• Vending machines
• Transport equipment
• Office facilities (e.g., electronic locks)
• Household appliances
• Mechanical equipment
• Game and slot machines
• Ticket machines
• Cash registers
