KQ2L08-03AS SMC FITTING

KQ2L08-03AS SMC FITTING
Technical Specifications

• Tube Connection Size: 8 mm (Push-in).
• Thread Connection Size: R 3/8 (BSPT male thread).
• Operating Pressure: -100 kPa to 1 MPa (-1 to 10 bar), making it suitable for both vacuum and pressure applications.
• Operating Temperature: -5 to 60°C (Air); 0 to 40°C (Water).
• Seal Method: Includes pre-applied thread sealant on the R thread.
• Materials:
  • Body: PBT (Polybutylene Terephthalate).
  • Threaded portion: Brass.
  • Release button: POM (Polyoxymethylene), typically light grey for metric sizes.
  • Seal/O-ring: NBR
